Our MMO linear anode consists of titanium wire coated with Ir-Ta mixed metal oxide catalyst, running in parallel with an insulated copper conductor. It is used for impressed current cathodic protection of buried structures, such as buried oil (gas) pipelines, underground tank, petrochemical container etc.
Polymeric Anode
|
Anode Dimension &Properties
|
|
|
Max operating current(in soil) |
52 mA/m（No coke anode bed）82mA/m（With coke anode bed） |
|
Max operating current (in water) |
10mA/m 7Mpa Constant water pressure |
|
Min bend radius |
500mm |
|
Outer Dia. |
38 mm |
|
Weight |
1.5kg/m |
|
Product length |
500 m Customizable |
MMO Linear Anode
|
Anode Dimension &Properties |
||
|
Outer Dia. |
38-40mm |
38-40mm |
|
MMO /Ti wire Dia |
1.5mm |
3mm |
|
Current output max |
300-1500mA/m |
300-1500mA/m |
|
Current density |
8A/m2 |
8A/m2 |
|
Current output |
38mA/m |
75mA/m |
|
Designed life |
40 year |
40 year |
|
Contact resistance |
≤0.0009Ω |
≤0.0009Ω |
|
Anode weight |
1.3-1.6Kg/m |
1.3-1.6Kg/m |
|
Length per roll |
500M,1000M |
500M,1000M |
